Print Cartridge (AIO)
M0C3/M0C4/M0C5/M0C6/M0C7 7-26 SM
Toner End Detection
No. Item
1. Toner end sensor
2. Agitator
3. Toner detection feeler
4. Toner supply roller
5. Development roller
6. Scraper
Toner end sensor
