Ricoh SP 3710DN - Original Jam (Adf;Ardf)

Jam Detection
M0C3/M0C4/M0C5/M0C6/M0C7 6-26 SM
6.5.2 ORIGINAL JAM (ADF/ARDF)
Jam Sensor Layout
The sensors used for jam detection are shown below.
1. Original set sensor
2. ADF feed sensor (ARDF feed sensor)
Jam Message List
Jam message Cause
ADF Original Misfeed
Original set sensor [1]
ADF feed sensor (ARDF feed sensor) [2]
