Ricoh SP 3710DN - Test Pattern Printing

Reports
M0C3/M0C4/M0C5/M0C6/M0C7 5-60 SM
For MF Four-Line LCD Models
1. Press the [User Tools] key.
2. Press the [
] or [ ] key to select [Printer Features], and then press the [OK] key.
3. Press the [
] or [ ] key to select [List/Test Print], and then press the [OK] key.
4. Press the [
] or [ ] key to select [Test page], and then press the [OK] key.
The test page is printed.
For MF Touch Panel Models
1. Press the [Setting] icon on the [Home] screen.
2. Press [Printer Features].
3. Press [List/Test Print].
4. Press [Test Page].
The test page is printed.
Test Page Example
5.5.5 TEST PATTERN PRINTING
Follow the test pattern print procedure below to print a test pattern.
