Product Overview
M0C3/M0C4/M0C5/M0C6/M0C7 7-14 SM
Boards, Switches
No. Description No. Description
1 Operation panel unit 6 Environment thermistor
2 Cooling fan 7 Speaker
3 HVP 8 Main board
4 PSU 9 Fax board
5
Front cover switch 10 Rear cover switch
