Ricoh SP 3710DN - Page 44

Image Quality Standards
SM 3-3 M0C3/M0C4/M0C5/M0C6/M0C7
Preventive
Maintenance
Copy
Item Specification Remarks
Resolution
100%/Enlargement: Min 3.6 lines/mm or
more
Reduction: Min 3.6 × M lines /mm or
more
M: Magnification
Not applicable when using the
ADF
Assured Image
Area
Leading edge: 4.2 mm
Left/Right: 4.2 mm
Trailing edge: 4.2 mm
Envelopes
Leading edge: 15 mm
Left/Right: 10 mm
Trailing edge: 10 mm
Magnification Error
Main: ± 1.25% or less
Sub: ± 1.25% or less
Except when duplexing.
Perpendicularity
± 1.2 mm/100 mm or less
Missing Image
Area
Left: 3.0 ± 2.5 mm
Right: 3.0 ± 2.0 mm (Reference value)
Leading edge: 4.0 ± 2.0 mm
Trailing edge: 4.0 ± 3.0 mm (Reference
value)
Scan
Item Specification Remarks
Magnification Error
Main: ± 0.5%
Sub: ± 1.5%
Magnification Error Deviation
Main: ±2.0%
Sub: ± 3.0%
Perpendicularity ± 0.55 deg
