ADF/ARDF Unit (Only MF Models)
SM 4-39 M0C3/M0C4/M0C5/M0C6/M0C7
and
5. Remove the ARDF drive unit [A].
When removing/attaching the ARDF drive unit, make sure to route the harnesses carefully
so that they will not be damaged.
6. Remove the ARDF motor assembly [A].
To Next Page
