10.3 Output / Input module, Module ID: 2, Outputs
Terminology Description
Abbrev.
(Old)
Cable
Interface
relay
Terminal in
cabinet
1 Supply valve 1 VSu1
(KD1)
#212b
black
RP11#1
(01)
91, 101, (111)
2 Drain valve 1 VDr1
(AD1)
#212b
blue
RP11#1
(02)
92, 102, (112)
3 Disinfected
valve 1 Open
VDi1
(AO1)
#202b
black
RP10#1
(01)
93, (113)
4 Disinfected
valve 1 Close
#202b
blue
RP10#1
(02)
103, (113)
5 Supply valve 2 VSu2
(KD2)
#212b
brown
RP11#1
(03)
94, 104, (114)
6 Drain valve 2 VDr2
(AD2)
#212b
grey
RP11#1
(04)
95, 105, (115)
7 Disinfected
valve 2 Open
VDi2
(AO2)
#202b
brown
RP10#1
(03)
96, (116)
8 Disinfected
valve 2 Close
#202b
grey
RP10#1
(04)
106, (116)
9 Supply valve 3 VSu3
(KD3)
#212b
red
RP11#1
(05)
97, 107, (117)
10 Drain valve 3 VDr3
(AD3)
#212b
purple
RP11#1
(06)
98, 108, (118)
11 Disinfected
valve 3 Open
VDi3
(AO3)
#202b
red
RP10#1
(05)
99, (119)
12 Disinfected
valve 3 Close
#202b
purple
RP10#1
(06)
109, (119)
13 Supply valve 4 VSu4
(KD4)
#212b
pink
RP11#1
(07)
100, 110,
(120)
14 Drain valve 4 VDr4
(AD4)
#212b
orange
RP11#1
(08)
121, 131,
(141)
15 Disinfected
valve 4 Open
VDi4
(AO4)
#202b
pink
RP10#1
(07)
122, (142)
16 Disinfected
valve 4 Close
#202b
orange
RP10#1
(08)
132, (142)
