<M> Settings / Unit / Characteristics
Node ID mon. radiation sensor
Here you enter the node ID of this Modbus sensor.
See the sensor housing for the node ID that you need
to enter here.
246
8.7 Drain group settings
<M> Settings / Drain group
Warming up UV lamps
Start conditions
Period
Control
Safeguards
Drain group characteristics
Control characteristics
8.7.1 Warming up UV lamps
<M> Settings / Drain groups / Warming up UV lamps
Supply water selection
l Fresh water: Select this option if the supply
water is drawn from a fresh water tank during the
warm-up phase of the UV lamps.
l Fresh+drain w.: Select this option if the supply
water is drawn from both a drain tank and a fresh
water tank during the warm-up phase of the UV
lamps. The ratio of water supplied by both tanks is
determined by the pre-blending control.
Warm-up time [hh:mm:ss]
This sets the duration required to warm up the UV
lamps. During this time, the water will either led back to
a drain tank or will be discharged from the system as
wastewater.
00:10:00 h
Enable discharge
l No: The water flowing past the quartz tubes
during the warm-up phase of the UV lamps will
return to a drain tank.
l Yes: The water flowing past quartz tubes during
the warm-up phase of the UV lamps will be
discharged as wastewater.
Yes
Only select No if
no water may
return to a drain
tank during the
warm-up phase.
