Ridder VitaLite-E - EC Pre-Blending Module (ID 4) Wiring

10.7 EC Pre-Blending Module ID: 4
Terminals
Description
Abbrev.
Cable
Signal
type
Terminal in
cabinet
27 Control EC sensor
High
EC1 sens
brown(40)
EC direct on
module
28 Control EC sensor
Low
sens green
(41)
direct on
module
29 Control EC sensor
Temp
sens
yellow(42)
PT1000 direct on
module
30 Control EC sensor
Temp
sens white
(43)
direct on
module
31 Monitor EC sensor
High
EC2 EC
32 Monitor EC sensor
Low
33 Monitor EC sensor
Temp
PT1000
34 Monitor EC sensor
Temp
35
36
37
38
39
40
41
42
