Ridder VitaLite-E - Output;Input Module (ID 3) Inputs

Terminals Description Abbrev. Cable
Signal
type
Terminal in
cabinet
14 Drain valve 8 VDr8 RP11#2
(08)
15 Disinfected valve 8
Open
VDi8 RP10#2
(07)
16 Disinfected valve 8
Close
RP10#2
(08)
10.6 Output / Input module 5th - 8th drain group,
Module ID: 3, Inputs
Terminals Description Abbrev.
Signal
type
Terminal in
cabinet
27 Drain level sensor 5 LDr5 317 4-20mA 231
28 Disinfected level
sensors 5..1
LDi5 4-20mA
29 Drain level sensor 6 LDr6 4-20mA
30 Disinfected level
sensors 6..1
LDi6 4-20mA
31 Drain level sensor 7 LDr7 4-20mA
32 Disinfected level
sensors 7..1
LDi7 4-20mA
33 Drain level sensor 8 LDr8 4-20mA
34 Disinfected level
sensors 8..1
LDi8 4-20mA 238
35 Total litre counter, Arad
Octave
4-20mA
36 Drain litre counter,
Arad Octave
4-20mA
37 T10 4-20mA
38
39
40
41
42
VitaLite
108
