VW Discharge
valve
Discharge
valve
Valve for discharging water into the sewer or a
tank.
Sensors
EC EC control
sensor
Control EC
sensor
Sensor for measuring the EC value of the drain
water blended with fresh water. This allows the
blending ratio between fresh water and drain
water to be controlled based on the EC value.
pH pH control
sensor
Control pH
sensor
Sensor for measuring the pH value of the water.
This allows the acidity of the water to be
controlled during the disinfection process and
the cleaning of the quartz tubes.
FDr Drain flow
sensor
Drain flow
sensor
Sensor for measuring the amount of drain
water.
FTo Total flow
sensor
Total flow
sensor
Sensor for measuring the total amount of
water. The total amount of water consists of a
ratio between fresh water and drain water.
LDi Disinfected
level
sensors
1..4
Disinfected
level
sensors
1..4
Sensors for measuring the amount of water in
the disinfected tanks.
LDr Drain level
sensors
1..4
Drain level
sensors
1..4
Sensors for measuring the amount of water in
the drain tanks.
Rad Radiation
sensor
Radiation
sensor
Sensor for measuring the UV-C radiation
intensity.
2.5.4 Certificates and declarations
The design and manufacture of the Ridder Growing Solutions VitaLite-E and C and
components supplied with it corresponds with the following standards:
CE directives
2014 / 30 / EU Electromagnetic Compatibility
2014 / 35 / EU Low Voltage Directive
CE standards
EN 61326-1:2013 EMC Emissions
EN 61326-1:2013 EMC Immunity
2.5.5 Original Equipment Manufacturers (OEM) information
Certain VitaLite-E and C components, such as the pump, are purchased from other
suppliers. Some of these components come with their own documentation. This
documentation is included with the unit. Please consult this documentation for the
correct use and maintenance of these components.
VitaLite
16
