8.7.6 Drain groups / Drain group characteristics
<M> Settings / Drain groups / Drain group characteristics
Drain tank selection
Here you select the number of the drain tank which should
supply the drain water of the drain group.
Select the
desired drain
tank for this
group.
Disinfected tank selection
Here you select the number of the disinfected tank in which
the disinfected water of the drain group should be collected.
Select the
desired
disinfected
tank for this
group.
Stop disinfection at end time
l No: Disinfection will continue until completed once the
end time has elapsed.
l Yes: Disinfection will stop immediately once the end
time has elapsed.
Yes, if
multiple
tanks are
used.
No, if one
tank is used.
Blnd. ratio on drain tank vol.
l No: The blending ratio will be calculated based on the
preset 'Blending ratio'.
l Yes: The blending ratio will be calculated based on the
volume of water in the drain tank.
Pause if acid tank empty
l No: If the acid tank is empty, then the alarm message
'Acid tank empty' will be generated and the unit will
continue with the disinfection process.
l Yes: If the acid tank is empty, then the alarm
message 'Acid tank empty' will be generated and the
unit will be paused. Refill the acid tank, then resume
the disinfection process by performing a manual start.
Yes
8.7.7 Drain groups / Control characteristics
<M> Settings / Drain groups / Control characteristics
Blending control gain
This is the gain (or amplification factor) of the pre-blending valve
control.
Control Pulse = Blending Ratio Error x Gain
Max. blend valve control pulse
This sets the maximum calculated control pulse for adjusting the
position of the servo valve per 10-second cycle.
Max. blending ratio decrease [%]
This sets the maximum percentage by which the 'Calculated
blending ratio' may be lowered as a result of EC control.
VitaLite
80
