2 Product information
This section describes the components and the functioning of the VitaLite-E and C.
2.1 Schematic representation of the unit
Each unit is built according to the principles in the diagram below. There may be some
minor differences depending on the unit that you are installing.
No. Description No. Description No. Description
A Acid tank 1 Pump EC EC sensor
(optional)
B Discharge pipe 2 Litre counter Rad Radiation
sensor
C Disinfected
(water) tank
3 Valve pH pH sensor
D Drain (water)
tank
4 Filter
E Pre-blending
system
(optional)
F Fresh water tank
VitaLite
