Ridder VitaLite-E - Output;Input Module (ID 2) Inputs

10.4 Output / Input module, Module ID: 2, Inputs
Terminology Description Abbrev. Cable
Signal
type
Terminal in
cabinet
27 Radiation sensor Rad IN Low,
IN Hi
VP23XL /
0-4mA
through
VP23XL on
module
28
29 System pump
alarm contact
T2, AP2 #34
grey
(brn)
MY4,
24VAC /
Contact
39, 49 alarm
= closed
30 Acid tank filled
contact
LAc, AP4 #34
black
(wht)
MY4,
24VAC /
Contact
69, 79 filled =
closed
31 Disinfected valves
closed contact
ESDi #34
red
(blue)
MY2,
24VAC /
Contact
72, 82 closed
= closed
32 External alarm
contact
Contact ?, ext alarm
= closed
33 Lamp malfunction
contact
Contact ?,
malfunction =
open
34 External filter
flushing contact
Contact ?, ext flush =
closed
35 Drain level sensor
1
LDr1 #316
black
4-20mA 201, 211, 221
36 Disinfected level
sensors 1..1
LDi1 #316
blue
4-20mA 202, 212, 222
37 Drain level sensor
2
LDr2 #316
brown
4-20mA 203, 213, 223
38 Disinfected level
sensors 2..1
LDi2 #316
grey
4-20mA 204, 214, 224
39 Drain level sensor
3
LDr3 #316
red
4-20mA 205, 215, 225
40 Disinfected level
sensors 3..1
LDi3 #316
purple
4-20mA 206, 216, 226
41 Drain level sensor
4
LDr4 #316
pink
4-20mA 207, 217, 227
