Ridder VitaLite-E - Output;Input Module (ID 3) Outputs

Terminology Description Abbrev. Cable
Signal
type
Terminal in
cabinet
42 Disinfected level
sensors 4..1
LDi4 #316
orange
4-20mA 208, 218, 228
10.5 Output / Input module 5th - 8th drain group,
Module ID: 3, Outputs
Terminals Description Abbrev. Cable
Signal
type
Terminal in
cabinet
1 Supply valve 5 VSu5 232 RP11#2
(01)
123, 133, (143)
2 Drain valve 5 VDr5 RP11#2
(02)
124
3 Disinfected valve 5
Open
VDi5 222 RP10#2
(01)
4 Disinfected valve 5
Close
RP10#2
(02)
5 Supply valve 6 VSu6 RP11#2
(03)
6 Drain valve 6 VDr6 RP11#2
(04)
7 Disinfected valve 6
Open
VDi6 RP10#2
(03)
8 Disinfected valve 6
Close
RP10#2
(04)
9 Supply valve 7 VSu7 RP11#2
(05)
129
10 Drain valve 7 VDr7 RP11#2
(06)
130
11 Disinfected valve 7
Open
VDi7 RP10#2
(05)
12 Disinfected valve 7
Close
RP10#2
(06)
13 Supply valve 8 VSu8 RP11#2
(07)
VitaLite
107
