To prevent damage during transport, certain components are:
not fastened tightly. If necessary, tighten the couplings.
shipped separately. Make sure that these components are installed
correctly.
Figure 4-1: Illustrations showing installation requirements
Location
Check whether the unit has been positioned correctly, see "Installation requirements"
on the previous page. In particular, make sure that there is sufficient space to
operate and maintain the unit. For instance, there must be enough space to install and
replace the lamps and quartz tubes. A quartz tube is 153 cm (60.2 in) in length.
Figure 4-2: Extra space to install and replace lamps and quartz tubes
VitaLite
23
