RKC INSTRUMENT RB Series User Manual

8. PARAMETER DESCRIPTION
IMR02C15-E4
8-16
Timer function
Factory default setting:
The screen is not displayed.
Up to four types of Timer functions are available.
Data range Factory set value
0 (Unused),
1 (Timer function 1) to 4 (Timer function 4)
0
• Timer function 1: Use the Set value (SV) set at SV selection to start
control when time has expired.
• Timer function 2: Use the Set value (SV) set at SV selection to stop
control when time has expired.
• Timer function 3: Link Set values from SV1 to SV4 to operate
ramp/soak control and continue to control the SV4
after the timer time has expired.
• Timer function 4: Link Set values from SV1 to SV4 to operate
ramp/soak control and stop controlling the SV4 after
the timer time.
Timer function is not displayed as the default when the block selection at
F02 [S.F02] (P. 8-65) is set to “1: No display” in the Engineering mode.
To show the parameter, set the value to “0: Display.”
For the operating procedure of the Timer function, refer to 7.2 Timer
Function (P. 7-5).
Related parameters
Parameter setting mode:
• Timer 1, Timer 2, Timer 3, Timer 4 (P. 8-15)
• Repeat execution times (P. 8-17)
Engineering mode:
• Timer function (P. 8-64)
TMFS
