RKC INSTRUMENT RB Series User Manual

8. PARAMETER DESCRIPTION
IMR02C15-E4 8-45
Continued from the previous page.
Continued on the next page.
Function block 04 (F04)
Function block 05
(F05)
F05.
SV1
(P. 8-71)
ATU
0000
SV1
Autotuning (AT)
STU
0000
SV1
Startup tuning (ST)
S.F05
0000
SV1
F05 block selection
(no display)
(P. 8-71) (P. 8-71) (P. 8-72)
Function block 06
(F06)
F06.
SV1
(P. 8-73)
P$
0030
SV1
Proportional band
[heat-side]
I
0240
SV1
Integral time
D
0060
SV1
Derivative time
ARW%
0100
SV1
Anti-reset windup
(ARW)
(P. 8-73) (P. 8-73) (P. 8-74) (P. 8-74)
Pc%
0100
SV1
Proportional band
[cool-side]
(P. 8-74)
DB$
0000
SV1
Overlap/Deadband
(P. 8-75)
PTU
0000
SV1
Fine tuning setting
(P. 8-75)
S.F06
0000
SV1
F06 block selection
(no display)
(P. 8-76)
Function block 07
(F07)
F07.
SV1
(P. 8-77)
HBA1
0000
SV1
Heater break alarm 1
(HBA1) set value
HBA2
0000
SV1
Heater break alarm 2
(HBA2) set value
LBA
0480
SV1
Control loop break
alarm (LBA) time
Lbd$
0000
SV1
LBA deadband
(LBD)
(P. 8-77) (P. 8-77) (P. 8-78) (P. 8-78)
S.F07
0000
SV1
F07 block selection
(no display)
(P. 8-79)
Function block 08
(F08)
F08.
SV1
(P. 8-80)
T
0020
SV1
Proportional cycle
time [heat-side]
MT
0000
SV1
Minimum ON/OFF time
of proportioning cycle
[heat-side]
OLH%
105.0
SV1
OLL%
105.0
SV1
(P. 8-80) (P. 8-80) (P. 8-81) (P. 8-81)
t
0020
SV1
Proportional cycle
time [cool-side]
(P. 8-81)
Mt
0000
SV1
Minimum ON/OFF time
of proportioning cycle
[cool-side]
(P. 8-82)
S.F08
0000
SV1
F08 block selection
(no display)
(P. 8-83)
Function block 09 (F09)
Output limiter high
Heat-side output
limiter (high)
Output limiter low
Cool-side output
limiter (high)
