Configure POINT I/O Modules in RSLogix 5000 Software 207
2. From the Fault/Program Action dialog, complete items, referring to the
table.
3. From the bottom of the dialog, perform one of the following:
• Click another tab at the top of the dialog.
or
• Click OK to save changes and close the dialog.
or
• Click Cancel to return to default values.
or
• Click Apply to save changes you made on any of the dialogs and
continue to display the dialog, noting that you enable the Apply
button when you make changes to any of the dialogs
For This Value Select Comments
Fault Mode • Hold Last State
• Go to Low Clamp
• Go to High Clamp
• Use Program
Value
Default is Go to Low Clamp.
Fault Value -32768…32767 Default is 0.
Program Mode • Hold Last State
• Go to Low Clamp
• Go to High Clamp
• Use Program
Value
Default is Go to Low Clamp.
Program Value -32768…32767 Default is 0.
