Remote Control
R&S
®
RTM20xx
365User Manual 1317.4726.02 ─ 01
15.2.12.5 Rise/Fall Time Search Configuration
SEARch:TRIGger:RISetime:SLOPe.................................................................................365
SEARch:TRIGger:LEVel:RISetime:LOWer........................................................................365
SEARch:TRIGger:LEVel:RISetime:UPPer........................................................................365
SEARch:TRIGger:RISetime:RANGe................................................................................365
SEARch:TRIGger:RISetime:TIME....................................................................................366
SEARch:TRIGger:RISetime:DELTa.................................................................................366
SEARch:TRIGger:RISetime:SLOPe <Polarity>
Sets the slope to be found.
Parameters:
<Polarity> POSitive | NEGative | EITHer
POSitive: to search for rise time.
NEGative to search for fall time.
EITHer: to search for rise and fall time
*RST: POS
Firmware/Software: FW 03.700
SEARch:TRIGger:LEVel:RISetime:LOWer <LowerLevel>
Sets the lower voltage threshold. When the signal crosses this level, the rise time mea-
surement starts or stops depending on the selected slope.
Parameters:
<LowerLevel> *RST: 400 mV
Default unit: V
Firmware/Software: FW 03.700
SEARch:TRIGger:LEVel:RISetime:UPPer <UpperLevel>
Sets the upper voltage threshold. When the signal crosses this level, the rise/fall time
measurement starts or stops depending on the selected slope.
Parameters:
<UpperLevel> *RST: 600 mV
Default unit: V
Firmware/Software: FW 03.700
SEARch:TRIGger:RISetime:RANGe <Range>
Sets how the measured rise or fall time is compared with the given limit(s).
To set the rise/fall time, use SEARch:TRIGger:RISetime:TIME.
To set the range ± Δt, use SEARch:TRIGger:RISetime:DELTa.
Command Reference
