Remote Control
R&S
®
RTM20xx
366User Manual 1317.4726.02 ─ 01
Parameters:
<Range> LONGer | SHORter | WITHin | OUTSide
LONGer
Finds rise/fall times longer than the given time.
SHORter
Finds rise/fall times shorter than the given time.
WITHin
Finds rise/fall times inside the range time ± Δt.
OUTSide
Finds rise/fall times outside the range time ± Δt.
*RST: LONG
Firmware/Software: FW 03.700
SEARch:
TRIGger:RISetime:TIME <Time>
Sets the reference rise or fall time, the nominal value for comparisons.
Parameters:
<Time> Range: Depends on various settings, mainly time base and
sample rate
*RST: 200e-6
Default unit: s
Firmware/Software: FW 03.700
SEARch:TRIGger:RISetime:DELTa <DeltaTime>
Sets a range Δt to the reference rise/fall time set with SEARch:TRIGger:RISetime:
TIME if SEARch:TRIGger:RISetime:RANGe on page 365 is set to Within or
Outside. The instrument finds rise/fall times inside or outside the range time ± Δt.
Parameters:
<DeltaTime> Range: Depends on various settings, mainly time base and
sample rate
*RST: 50e-6
Default unit: s
Firmware/Software: FW 03.700
15.2.12.6 Runt Search Configuration
SEARch:TRIGger:RUNT:POLarity...................................................................................367
SEARch:TRIGger:LEVel:RUNT:LOWer............................................................................367
SEARch:TRIGger:LEVel:RUNT:UPPer.............................................................................367
SEARch:TRIGger:RUNT:RANGe.....................................................................................367
SEARch:TRIGger:RUNT:WIDTh......................................................................................368
SEARch:TRIGger:RUNT:DELTa......................................................................................368
Command Reference
