Figure 1.2: Control panel ROWE Scan 600
If you want to mark the favorite keys of the control panel, use a conventional
permanent marker. Please use household cleaning agent to remove or clean it.
Figure 1.3 shows the back as well as the side box of ROWE Scan 600. There, you see the
following connections and / or switches:
1. On/Off switch
9. Mains connection
10. USB slot to connect scanner to PC
11. USB slot to connect USB slot of scanner to USB slot of PC (see 2.12)
12. USB slot of scanner for USB data carrier (only in connection with 4., see 2.12)
