2.1 Erecting Scanner
Place the scanner either on the suitable ROWE stand, ROWE MFP stand (see Optional
Accessories, Chapter 1.2 on Page 10), or on a sturdy table. Erect the scanner in a way
that document feed and outlet can be accessed from all sides.
Do not yet connect the scanner to power supply or computer.
Do not lift the scanner by grabbing the side boxes (also see Chapter 1.4 on
Page 14).
2.2 Starting Software Installation
In order to install the software, you need
the supplied CD-Rom. Switch the computer
ON which is not yet connected to the
scanner. Put the CD-Rom into the CD-Rom
drive of the PC.
Usually, installation of the software starts
automatically. If not, start from the CD by
double-clicking "autorun.exe".
The dialog box shown in Figure 2.1 appears
from which you simply select "Install“.
Figure 2.1: Installation screen
The installation process has been started
and you are first prompted to select the
language.
Figure 2.2: Selection of language
