ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 51
Table 25. ZoneFlex 7962 side panel elements
Number LED/Button Name Description
1 OPT LED Not used in this model.
2DIR LED •
Off: The Access Point is not being managed by
ZoneDirector (standalone mode).
•
Green: The Access Point is being managed by
ZoneDirector.
• Slow flashing green (one flash every two seconds):
The Access Point is being managed by
ZoneDirector, but is currently unable to
communicate with ZoneDirector.
• Fast flashing green (two flashes every second): The
Access Point is being managed by ZoneDirector and
is currently receiving configuration settings
(provisioning) or a firmware update.
3 2.4G LED (WLAN) • Off: The WLAN service is down.
• Green: The WLAN service is up, at least one client is
associated, and signal quality is good (RSSI >= 15).
• Flashing green (two flashes every second): The
WLAN service is up but no clients are associated.
• Amber: The WLAN service is up, at least one client
is associated, but signal quality is poor (RSSI < 15).
