Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 52
4 5G LED (WLAN)
• Off: The WLAN service is down.
• Green: The WLAN service is up, at least one client is
associated (standalone), or at least one downlink
MAP is connected (RAP), or uplink RAP is connected
(MAP), and signal quality is good (RSSI >= 15).
• Fast flashing green (two flashes every second): The
WLAN service is up but no clients are associated
(standalone), no downlink MAPs are connected
(RAP), or no uplink RAP is connected (MAP).
• Amber: The WLAN service is up, at least one wireless
client is associated (standalone), or at least one
downlink MAP is connected (RAP), or uplink RAP is
connected (MAP), but signal quality is poor (RSSI <
15).
5HARD RESET
Button
Pushing and quickly releasing this internal button
reboots the AP. Pushing and holding it for six seconds
resets the AP to factory default settings.
CAUTION! Resetting the AP to factory default settings
erases all previously configured settings.
6 Sliding Door Protects the ports, buttons, and connector on the rear
panel.
7 Kensington Lock The Kensington lock feature, located on the opposite
side of the unit from the pictured LEDs, is designed to
prevent the sliding door from opening, thus locking the
unit. The Kensington lock works with a Kensington
MicroSaver lock.
8 Power LED (front) • Off: Off.
• Amber: Boot up in process.
• Green: On.
Table 25. ZoneFlex 7962 side panel elements (Continued)
Number LED/Button Name Description
