Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 60
Rear Panel
The rear panel of the R300 features one 10/100/1000 PoE Ethernet port, power
socket and reset button. See Table 3 2 for a description of each rear panel part.
DIR LED • Off: The Access Point is not being managed by ZoneDirector
(standalone mode).
• Green: The Access Point is being managed by ZoneDirector.
• Slow flashing green (one flash every two seconds): The
Access Point is being managed by ZoneDirector, but is
currently unable to communicate with ZoneDirector.
• Fast flashing green (two flashes every second): The Access
Point is being managed by ZoneDirector and is currently
receiving configuration settings (provisioning) or a firmware
update.
2.4G LED (WLAN) • Off: The WLAN service is down.
• Green: The WLAN service is up, at least one client is
associated, and signal quality is good (RSSI >= 15).
• Flashing green (two flashes every second): The WLAN service
is up but no clients are associated.
• Amber: The WLAN service is up, at least one client is
associated, but signal quality is poor (RSSI < 15).
5G LED (WLAN) • Off: The WLAN service is down.
• Green: The WLAN service is up, at least one client is
associated, and signal quality is good (RSSI >= 15).
• Fast flashing green (two flashes every second): The WLAN
service is up but no clients are associated.
• Amber: The WLAN service is up, at least one wireless client is
associated, but signal quality is poor (RSSI < 15).
Table 31. R300 front panel elements (Continued)
LED Description
