Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 75
WARNING! For units using Power over Ethernet (PoE). These products and all
interconnected equipment must be installed indoors within the same building,
including the associated LAN connections, as defined by Environment A of the IEEE
802.3af Standard.
Table 40. R700 rear panel elements
Number Item Name Description
1 ETHERNET +
PoE Port
One RJ-45 port for a 10/100/1000 PoE (Power over
Ethernet, 802.3af/at) connection. (The R700 is a Class 3
device.)
2 ETHERNET
Port
One RJ-45 port for a 10/100/1000 connection.
3 12V 1.5A Power
Socket
Connect the power adapter (12 VDC/1.25A) to this socket.
Power can also be supplied via the ETHERNET + PoE port.
4 RESET Button Pressing, and then quickly releasing this internal button
reboots the AP. Pressing and holding it for six seconds
resets the AP to factory default settings.
CAUTION! Resetting the AP to factory default settings
erases all settings that you configured previously.
Table 41. Behavior of Ethernet port LEDs on R700
LEDs Description
Off Not connected
Amber + Green Connected to 10Mbps device
Amber Connected to 100Mbps device
Green Connected to 1000Mbps device
