Installing the Access Point
Before You Begin
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 81
ZoneFlex R300, 7982, 7372, 7352, 7351, 7363, 7343, 7341
and 7321 Orientation
ZoneFlex R300, 7982, 7372, 7352, 7351, 7363, 7343, 7341 and 7321 have a more
rounded coverage area and less horizontal range (when mounted horizontally)
compared to the dome-shaped ZoneFlex 7962 AP.
Figure 37. ZoneFlex R300, 7982, 7372, 7352, 7351, 7363, 7343, 7341 and 7321
recommended ceiling mounting orientation
Limited
Reach
Limited
Reach
Excellent
Reach
Excellent
Reach
Excellent
Reach
