Installing the Access Point
Before You Begin
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 82
When wall mounted, ZoneFlex R300, 7982, 7372, 7352, 7351, 7363, 7343, 7341
and 7321 should be staggered to maximize coverage.
Figure 38. ZoneFlex R300, 7982, 7372, 7352, 7351, 7363, 7343, 7341 and 7321
recommended wall mounting orientation
Excellent
Reach
Excellent
Reach
Excellent
Reach
Limited
Reach
