Ruijie RG-WLAN Series User Manual

Configuration Guide Configuring NAT
 Configure the LAN interface to connect to the intranet as the NAT inside interface unless otherwise stated.
 Configuring the NAT Outside Interface
 Mandatory configuration.
 Configure the WAN interface to connect to the extranet as the NAT outside interface unless otherwise stated.
 Configuring Static NAT
 Optional configuration.
 Configure static NAT in global configuration mode when a small number of users in the intranet need to access the
extranet.
 Configuring Dynamic NAT
 Optional configuration.
 Configure dynamic NAT in global configuration mode when a large number of users in the intranet need to access
the extranet.
Verification
N/A
Commands
 Configuring the NAT Inside Interface and NAT Outside Interface
Command
Syntax
ip nat { inside | outside }
Parameter
Description
inside: inside interface
outside: outside interface
Command
Mode
Interface configuration mode
Configuration
Usage
NAT does not work on a data packet unless a route exists between the outside interface and the inside
interface and the data packet meets a certain rule. Therefore, at least one inside interface and one
outside interface need to be configured on the router.
 Configuring Static NAT
Command
Syntax
ip nat inside source static local-address global-address [ permit-inside ] [ netmask mask ] [ match
interface ]
Parameter
Description
local-address: inside address
global-address: outside address
permit-inside: permits intranet users to access the local-ip host using global-ip.
netmask mask: network-segment-to-network-segment address
match interface: specifies the egress interface.
Command
Mode
Global configuration mode
Configuration
Usage
-
