Ruijie RG-WLAN Series User Manual

Configuration Guide Managing Routes
 Configure static routes on each device.
R1
R1# configure terminal
R1(config)# ip route 1.1.2.0 255.255.255.0 GigabitEthernet 0/2 1.1.12.2
R1(config)# ip route 1.1.3.0 255.255.255.0 GigabitEthernet 0/3 1.1.13.3
R2
R2# configure terminal
R2(config)# ip route 1.1.1.0 255.255.255.0 GigabitEthernet 0/1 1.1.12.1
R2(config)# ip route 1.1.3.0 255.255.255.0 GigabitEthernet 0/3 1.1.23.3
R3
R3# configure terminal
R3(config)# ip route 1.1.2.0 255.255.255.0 GigabitEthernet 0/2 1.1.23.2
R3(config)# ip route 1.1.1.0 255.255.255.0 GigabitEthernet 0/1 1.1.13.1
Verification
 Display the routing table.
R1
R1# show ip route
Codes: C - Connected, L - Local, S - Static
R - RIP, O - OSPF, B - BGP, I - IS-IS
N1 - OSPF NSSA external type 1, N2 - OSPF NSSA external type 2
E1 - OSPF external type 1, E2 - OSPF external type 2
SU - IS-IS summary, L1 - IS-IS level-1, L2 - IS-IS level-2
IA - Inter area, * - candidate default
Gateway of last resort is no set
C 1.1.1.0/24 is directly connected, GigabitEthernet 0/0
C 1.1.1.1/32 is local host.
S 1.1.2.0/24 [1/0] via 1.1.12.2, GigabitEthernet 0/2
S 1.1.3.0/24 [1/0] via 1.1.13.3, GigabitEthernet 0/2
C 1.1.12.0/24 is directly connected, GigabitEthernet 0/2
C 1.1.12.1/32 is local host.
C 1.1.13.0/24 is directly connected, GigabitEthernet 0/3
C 1.1.13.1/32 is local host.
R2
R2# show ip route
Codes: C - Connected, L - Local, S - Static
R - RIP, O - OSPF, B - BGP, I - IS-IS
N1 - OSPF NSSA external type 1, N2 - OSPF NSSA external type 2
E1 - OSPF external type 1, E2 - OSPF external type 2
SU - IS-IS summary, L1 - IS-IS level-1, L2 - IS-IS level-2
IA - Inter area, * - candidate default
Gateway of last resort is no set
S 1.1.1.0/24 [1/0] via 1.1.12.1, GigabitEthernet 0/0
C 1.1.2.0/24 is directly connected, GigabitEthernet 0/0
C 1.1.2.1/32 is local host.
