Chapter 3. Installing Product 3 – 35
3.6.10.3. Result
Select how measurement results are displayed.
■ Position on 2D Mode
Reposition the measurement results when 2D Mode is selected.
– Left-Top: Measurement results are displayed in the top left corner of the screen.
– Left-Bottom: Measurement results are displayed in the bottom left corner of the screen.
– Right -Bottom: Measurement results are displayed in the bottom right corner of the screen.
– Right-Top: Measurement results are displayed in the top right-hand corner of the screen.
– Custom: Measurement results are displayed in a location selected by the user.
■ Position on M/D Mode
Move the measurement results.
– Left-Top: Move the measurement results towards the top left-hand corner of the screen.
– Left-Bottom: Moves the m easurem ent res ults towards the bottom left corner of the screen.
– Right-Bottom: Moves the measurement results towards the bottom right corner of the
screen.
– Right-Top: Moves the measurement results towards the top right corner of the screen.
– Custom: Measurement results are moved to a location selected by the user.
■ Font Size
Select the size of the font used for the measurement results.
■ Show Background
Set the background of the measurement results to black (On) or transparent (Off).
3.6.10.4. Key
■ Trackball Operation
Set the motion of the trackball when using Caliper or Measure.
– Marker: Stand-by and ready to measure; display the basic marker on the measurement
screen.
– Cine: Ready to select a Cine frame by using the trackball.
■ Set Measurement on Store
Turn the function on or off that automatically completes measurements when the Store key
on the control pad is pressed while a measurement is being taken.
