Chapter 3. Installing Product 3 – 37
3.6.10.6. Measure
Library in the Measure category is shown.
■ Application
Select an application.
■ Create
Create a USERGROUP other than default group. A USERLABEL can be created within a
created group.
NOTE
‘USERLABEL’ can be edited.
■ Delete
A newly generated ‘LABEL’ can be deleted.
3.6.10.7. Caliper
Specify whether additional information will be shown along with the basic measurement values
when basic measurements are taken by pressing the control panel’s Caliper button. If this
option is selected, the additional information will be saved as an output along with the
measurement results.
Setting ‘Application’ to General will change the items in ‘D Trace’. Setting ‘Application’ to
Cardiac will change the items in ‘D Trace’ and ‘D Velocity’.
‘Cardiac’ setting is activated when the probe setting i
s Cardiac.
Select the default tool that functions in the measurement cursor state for each Image mode.
• 2D Mode: Distance, Trace, Trace Length, Ellipse, Open Spline, Closed Spline, Distance
Stenosis, Trace Length Stenosis, Open Spline Stenosis, Ellipse Stenosis, Trace Stenosis,
Closed Spline Stenosis, Ellipse Trace Stenosis, 2 Lines Angle, 3 Point Angle, 1 Dist Volume,
2 Dist Volume, 3 Dist Volume, Ellipse Volume, Ellipse + Dist Vol, Disk Volume
• D Mode: Velocity, Velocity (Cardiac), Accel, Time(D), HR(D), RI, Auto Trace, Limited Trace,
Manual Trace, Auto Trace (Cardiac), Limited Trace (Cardiac), Manual Trace (Cardiac), Dist
Volume Flow, Trace Length Volume Flow, Open Spline Volume Flow, Ellipse Volume Flow,
Trace Volume Fl ow, Closed Spline Volum e Flow, S/D Ratio, D/S Ratio, Velocity(F), Velocity(F)
(Cardiac), Auto Trace(F), Limited Trace(F), Manual Trace(F), Auto Trace(F) (Cardiac), Limited
Trace(F) (Cardiac), Manual Trace(F) (Cardiac), Dist Volume Flow(F), Trace Length Volume
Flow(F), Open Spline Volume Flow(F), Ellipse Volume Flow(F), Trace Volume Flow(F),
Closed Spline Volume Flow(F), S/D Ratio(F), D/S Ratio(F)
• M Mode: Distance, Slope, Time(M), HR(M)
To Next Page
