Sanyo PLC HF10000L Service Manual

-143-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 1
29 (Sub) Filed Enable 0 - 1 1
30 (Sub) FLDBEG 0 - 15 1
31 (Sub) FLDEND 0 - 15 10
32 (Sub) PHASE 0 - 63 16
900 Lamp Option
0 Lamp Replacement Display 0 - 1 1
1 Lamp Go Out 0 - 1 0
901 Lamp Warning Time
0 Lamp Warning Time (NORMAL) 0 - 16 4
1 Lamp WarningTime (ECO) 0 - 16 6
910 Dimmer Control
0 Dimmer SW 0 - 1 0
4 DIMMER LEVEL NORMAL 0 - 15 15
5 DIMMER LEVEL ECO 0 - 15 15
10 Lamp 1 Manual Dimmer Level 0 - 15 15
11 Lamp 2 Manual Dimmer Level 0 - 15 15
930 Lamp Mode Change
0 All Lamp Mode 0 - 11 11
1 3L Mode 1 (Lamp(1)) 0 - 10 0
2 3L Mode 2 (Lamp(2)) 0 - 10 0
931 Lamp Factory Time
0 Lamp Mode Chg No. LAMP ON 50 - 200 50
1 Lamp Mode Chg LAMP ON 50 - 200 120
980 Auto Gamma Calibration
0 Aut Gamma CALC Execute Auto Gamma Calicuration when the value is set to 10. 0 - 10 0
1 Auto Gamma ACLC Mode 0 - 1 1
982 Auto Gamma Calibration Ye Auto
0 Ye Auto: PC Standard : LVL_USE [Unit] 0.01 1 - 999 100
1 Ye Auto: PC Standard :W_SXY_0 [Unit] 0.001
0 - 999 310
2 Ye Auto: PC Standard :W_SXY_1 [Unit] 0.001 0 - 999 330
3 Ye Auto: PC Standard :B_SXY_0 [Unit] 0.001 0 - 999 310
4 Ye Auto: PC Standard :B_SXY_1 [Unit] 0.001 0 - 999 330
5 Ye Auto: PC Standard :LMIT_CONTRAST 100 - 5000 5000
6 Ye Auto: PC Standard :CAL_CONT Result Contrast Display only --
7 Ye Auto: PC Standard :CONT_USE [Unit] 0.001
100 - 5000 1000
8 Ye Auto: PC Real : LVL_USE [Unit] 0.01 1 - 999 85
9 Ye Auto: PC Real :W_SXY_0 [Unit] 0.001 0 - 999 315
10 Ye Auto: PC Real :W_SXY_1 [Unit] 0.001 0 - 999 340
11 Ye Auto: PC Real :B_SXY_0 [Unit] 0.001 0 - 999 315
12 Ye Auto: PC Real :B_SXY_1 [Unit] 0.001 0 - 999 340
13 Ye Auto: PC Real :LMIT_CONTRAST 100 - 5000 1800
14 Ye Auto: PC Real :CAL_CONT Result Contrast --
15 Ye Auto: PC Real :CONT_USE [Unit] 0.001 100 - 5000 500
16 Ye Auto: PC Dynamic : LVL_USE [Unit] 0.01
1 - 999 100
17 Ye Auto: PC Dynamic :W_SXY_0 [Unit] 0.001 0 - 999 300
18 Ye Auto: PC Dynamic :W_SXY_1 [Unit] 0.001 0 - 999 320
19 Ye Auto: PC Dynamic :B_SXY_0 [Unit] 0.001 0 - 999 300
20 Ye Auto: PC Dynamic :B_SXY_1 [Unit] 0.001 0 - 999 320
21 Ye Auto: PC Dynamic :LMIT_CONTRAST 100 - 5000 5000
22 Ye Auto: PC Dynamic :CAL_CONT Result Contrast --
23 Ye Auto: PC Dynamic :CONT_USE [Unit] 0.001 100 - 5000 1000
24 Ye Auto: AV Standard : LVL_USE [Unit] 0.01 1 - 999 90
25 Ye Auto: AV Standard :W_SXY_0 [Unit] 0.001
0 - 999 310
26 Ye Auto: AV Standard :W_SXY_1 [Unit] 0.001 0 - 999 330
27 Ye Auto: AV Standard :B_SXY_0 [Unit] 0.001 0 - 999 310
28 Ye Auto: AV Standard :B_SXY_1 [Unit] 0.001 0 - 999 330
29 Ye Auto: AV Standard :LMIT_CONTRAST
100 - 5000 2000
30 Ye Auto: AV Standard :CAL_CONT Result Contrast --
31 Ye Auto: AV Standard :CONT_USE [Unit] 0.001
100 - 5000 500
32 Ye Auto: AV Cinema : LVL_USE [Unit] 0.01
1 - 999 80
982 GAMMA Adjustment (Automatic Calibration) * White Balance Adj.
0 Ye Auto: PC Standard : LVL_USE [Unit] 0.01 1 ~ 999 100
1 Ye Auto: PC Standard :W_SXY_0 [Unit] 0.001 0 ~ 999 310
2 Ye Auto: PC Standard :W_SXY_1 [Unit] 0.001 0 ~ 999 330
3 Ye Auto: PC Standard :B_SXY_0 [Unit] 0.001 0 ~ 999 0
4 Ye Auto: PC Standard :B_SXY_1 [Unit] 0.001 0 ~ 999 0
5 Ye Auto: PC Standard :LMIT_CONTRAST 100 ~ 5000 5000
6 Ye Auto: PC Standard :CAL_CONT Result Contrast
7 Ye Auto: PC Standard :CONT_USE [Unit] 0.001 100 ~ 5000 1000
8 Ye Auto: PC Real : LVL_USE [Unit] 0.01 1 ~ 999 85
9 Ye Auto: PC Real :W_SXY_0 [Unit] 0.001 0 ~ 999 315
10 Ye Auto: PC Real :W_SXY_1 [Unit] 0.001 0 ~ 999 340
11 Ye Auto: PC Real :B_SXY_0 [Unit] 0.001 0 ~ 999 315
12 Ye Auto: PC Real :B_SXY_1 [Unit] 0.001 0 ~ 999 340
13 Ye Auto: PC Real :LMIT_CONTRAST 100 ~ 5000 1800
14 Ye Auto: PC Real :CAL_CONT Result Contrast
15 Ye Auto: PC Real :CONT_USE [Unit] 0.001 100 ~ 5000 500
16 Ye Auto: AV Standard : LVL_USE [Unit] 0.01 1 ~ 999 90
17 Ye Auto: AV Standard :W_SXY_0 [Unit] 0.001 0 ~ 999 310
18 Ye Auto: AV Standard :W_SXY_1 [Unit] 0.001 0 ~ 999 330
19 Ye Auto: AV Standard :B_SXY_0 [Unit] 0.001 0 ~ 999 310
20 Ye Auto: AV Standard :B_SXY_1 [Unit] 0.001 0 ~ 999 330
21 Ye Auto: AV Standard :LMIT_CONTRAST 100 ~ 5000 2000
22 Ye Auto: AV Standard :CAL_CONT Result Contrast
23 Ye Auto: AV Standard :CONT_USE [Unit] 0.001 100 ~ 5000 500
24 Ye Auto: AV Cinema : LVL_USE [Unit] 0.01 1 ~ 999 80
25 Ye Auto: AV Cinema :W_SXY_0 [Unit] 0.001 0 ~ 999 315
26 Ye Auto: AV Cinema :W_SXY_1 [Unit] 0.001 0 ~ 999 328
27 Ye Auto: AV Cinema :B_SXY_0 [Unit] 0.001 0 ~ 999 315
28 Ye Auto: AV Cinema :B_SXY_1 [Unit] 0.001 0 ~ 999 328
29 Ye Auto: AV Cinema :LMIT_CONTRAST 100 ~ 5000 1400
30 Ye Auto: AV Cinema :CAL_CONT Result Contrast
31 Ye Auto: AV Cinema :CONT_USE [Unit] 0.001 100 ~ 5000 500
32 Ye Off: PC Standard : LVL_USE [Unit] 0.01 1 ~ 999 85
33 Ye Off: PC Standard :W_SXY_0 [Unit] 0.001 0 ~ 999 287
34 Ye Off: PC Standard :W_SXY_1 [Unit] 0.001 0 ~ 999 317
35 Ye Off: PC Standard :B_SXY_0 [Unit] 0.001 0 ~ 999 0
36 Ye Off: PC Standard :B_SXY_1 [Unit] 0.001 0 ~ 999 0
37 Ye Off: PC Standard :LMIT_CONTRAST 100 ~ 5000 5000
38 Ye Off: PC Standard :CAL_CONT Result Contrast
39 Ye Off: PC Standard :CONT_USE [Unit] 0.001 100 ~ 5000 500
40 Ye Off: PC Real : LVL_USE [Unit] 0.01 1 ~ 999 75
41 Ye Off: PC Real :W_SXY_0 [Unit] 0.001 0 ~ 999 292
42 Ye Off: PC Real :W_SXY_1 [Unit] 0.001 0 ~ 999 323
43 Ye Off: PC Real :B_SXY_0 [Unit] 0.001 0 ~ 999 292
44 Ye Off: PC Real :B_SXY_1 [Unit] 0.001 0 ~ 999 323

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
