Sanyo PLC HF10000L Service Manual

-144-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
33 Ye Auto: AV Cinema :W_SXY_0 [Unit] 0.001 0 - 999 315
34 Ye Auto: AV Cinema :W_SXY_1 [Unit] 0.001
0 - 999 328
35 Ye Auto: AV Cinema :B_SXY_0 [Unit] 0.001 0 - 999 315
36 Ye Auto: AV Cinema :B_SXY_1 [Unit] 0.001 0 - 999 328
37 Ye Auto: AV Cinema :LMIT_CONTRAST 100 - 5000 1400
38 Ye Auto: AV Cinema :CAL_CONT Result Contrast --
39 Ye Auto: AV Cinema :CONT_USE [Unit] 0.001 100 - 5000 500
40 Ye Auto: Av Dynamic : LVL_USE [Unit] 0.01 1 - 999 100
41 Ye Auto: AV Dynamic :W_SXY_0 [Unit] 0.001 0 - 999 300
42 Ye Auto: AV Dynamic :W_SXY_1 [Unit] 0.001 0 - 999 320
43 Ye Auto: AV Dynamic :B_SXY_0 [Unit] 0.001 0 - 999 300
44 Ye Auto: AV Dynamic :B_SXY_1 [Unit] 0.001 0 - 999 320
45 Ye Auto: AV Dynamic :LMIT_CONTRAST 100 - 5000 5000
46 Ye Auto: AV Dynamic :CAL_CONT Result Contrast --
47 Ye Auto: AV Dynamic :CONT_USE [Unit] 0.001 100 - 5000 1000
983 Auto Gamma Calibration Ye OFF: Normal Display
0 Ye Off: PC Standard : LVL_USE [Unit] 0.01 1 - 999 85
1 Ye Off: PC Standard :W_SXY_0 [Unit] 0.001 0 - 999 287
2 Ye Off: PC Standard :W_SXY_1 [Unit] 0.001 0 - 999 317
3 Ye Off: PC Standard :B_SXY_0 [Unit] 0.001
0 - 999 298
4 Ye Off: PC Standard :B_SXY_1 [Unit] 0.001 0 - 999 317
5 Ye Off: PC Standard :LMIT_CONTRAST 100 - 5000 5000
6 Ye Off: PC Standard :CAL_CONT Result Contrast Display only --
7 Ye Off: PC Standard :CONT_USE [Unit] 0.001 100 - 5000 1000
8 Ye Off: PC Real : LVL_USE [Unit] 0.01 1 - 999 75
9 Ye Off: PC Real :W_SXY_0 [Unit] 0.001 0 - 999 292
10 Ye Off: PC Real :W_SXY_1 [Unit] 0.001 0 - 999 323
11 Ye Off: PC Real :B_SXY_0 [Unit] 0.001 0 - 999 292
12 Ye Off: PC Real :B_SXY_1 [Unit] 0.001 0 - 999 323
13 Ye Off: PC Real :LMIT_CONTRAST 100 - 5000 1400
14 Ye Off: PC Real :CAL_CONT Result Contrast --
15 Ye Off: PC Real :CONT_USE [Unit] 0.001 100 - 5000 500
16 Ye Off: PC Dynamic : LVL_USE [Unit] 0.01 1 - 999 100
17 Ye Off: PC Dynamic :W_SXY_0 [Unit] 0.001 0 - 999 285
18 Ye Off: PC Dynamic :W_SXY_1 [Unit] 0.001 0 - 999 315
19 Ye Off: PC Dynamic :B_SXY_0 [Unit] 0.001 0 - 999 285
20 Ye Off: PC Dynamic :B_SXY_1 [Unit] 0.001 0 - 999 315
21 Ye Off: PC Dynamic :LMIT_CONTRAST
100 - 5000 5000
22 Ye Off: PC Dynamic :CAL_CONT Result Contrast --
23 Ye Off: PC Dynamic :CONT_USE [Unit] 0.001 100 - 5000 1000
24 Ye Off: AV Standard : LVL_USE [Unit] 0.01 1 - 999 75
25 Ye Off: AV Standard :W_SXY_0 [Unit] 0.001 0 - 999 287
26 Ye Off: AV Standard :W_SXY_1 [Unit] 0.001 0 - 999 317
27 Ye Off: AV Standard :B_SXY_0 [Unit] 0.001
0 - 999 287
28 Ye Off: AV Standard :B_SXY_1 [Unit] 0.001 0 - 999 317
29 Ye Off: AV Standard :LMIT_CONTRAST 100 - 5000 1700
30 Ye Off: AV Standard :CAL_CONT Result Contrast --
31 Ye Off: AV Standard :CONT_USE [Unit] 0.001 100 - 5000 500
32 Ye Off: AV Cinema : LVL_USE [Unit] 0.01 1 - 999 60
33 Ye Off: AV Cinema :W_SXY_0 [Unit] 0.001 0 - 999 313
34 Ye Off: AV Cinema :W_SXY_1 [Unit] 0.001 0 - 999 329
35 Ye Off: AV Cinema :B_SXY_0 [Unit] 0.001 0 - 999 313
36 Ye Off: AV Cinema :B_SXY_1 [Unit] 0.001
0 - 999 329
37 Ye Off: AV Cinema :LMIT_CONTRAST 100 - 5000 1200
38 Ye Off: AV Cinema :CAL_CONT Result Contrast --
39 Ye Off: AV Cinema :CONT_USE [Unit] 0.001 100 - 5000 500
40 Ye Off: Av Dynamic : LVL_USE [Unit] 0.01 1 - 999 100
41 Ye Off: AV Dynamic :W_SXY_0 [Unit] 0.001 0 - 999 285
42 Ye Off: AV Dynamic :W_SXY_1 [Unit] 0.001 0 - 999 315
43 Ye Off: AV Dynamic :B_SXY_0 [Unit] 0.001 0 - 999 285
44 Ye Off: AV Dynamic :B_SXY_1 [Unit] 0.001 0 - 999 315
45 Ye Off: AV Dynamic :LMIT_CONTRAST
100 - 5000 5000
46 Ye Off: AV Dynamic :CAL_CONT Result Contrast --
47 Ye Off: AV Dynamic :CONT_USE [Unit] 0.001 100 - 5000 1000
984 Auto Gamma Calibration Ye OFF: Multi Display
0 Ye Off: PC Standard : LVL_USE [Unit] 0.01 1 - 999 85
1 Ye Off: PC Standard :W_SXY_0 [Unit] 0.001
0 - 999 300
2 Ye Off: PC Standard :W_SXY_1 [Unit] 0.001
0 - 999 360

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
