4.7 Keypad
The keypad is used for entering values in entry fields. If an entry field is activated: The alphanumeric keypad
ornumerical keypad appears.
2
4 3
1
Fig. 7: Alphanumeric keypad and numerical keypad (example)
Pos. Name Description
1 Input field
2 Input assistance Indicates which values can be entered in the entry field,
e.g.onlynumbers.
3 Numeric keypad
4 Alphanumeric keypad
4.8 Status Display of the Buttons
Symbol Name Description
Predominant button Indicates that the function must be executed.
Thebutton is color-highlighted.
Secondary button Indicates that the function can be executed.
Thebutton is highlighted gray.
Inactive button Indicates that the function currently cannot
beexecuted. The button is grayed out.
