62 Operating Instructions Cubis
®
MCA
System Settings
7.7.7 Parameters in the “Connections / Connectors” Menu
Parameter Setting Values Explanation
USB Connector name Saves the entered name for a USB stick.
Destination directory Saves the name of a destination directory.
YDP30-NET Connector name Saves the entered name for a YDP30-NET.
IP or host Enter the IP or host address for the printer.
Port Define the port for the printer, e.g. “9100”.
FTP or FTPS Connector name If the QAPP extension has been activated:
Saves the entered name of an FTP or FTPS server.
IP address If the QAPP extension has been activated:
Enter the IP address for the device.
Port If the QAPP extension has been activated:
Define the port for thedevice, e.g. “21”.
Sub-directory If the QAPP extension has been activated:
Saves the name ofasub-directory.
User If the QAPP extension has been activated:
Saves the name of theuser.
Password If the QAPP extension has been activated:
Saves the password for FTP or FTPS access.
Network printer Connector name Saves the entered name for a network printer.
IP or host Enter the IP or host address for the printer.
Protocol Define the protocol for the printer: Socket, IPP, HTTP or LDP
SMB Connector name If the QAPP extension “Windows File Server” has been activated:
Saves the entered name of a Windows file server.
//Host/Share If the QAPP extension “Windows File Server” has been activated:
Enter the host and share names of the Windows file server.
Sub-directory If the QAPP extension “Windows File Server” has been activated:
Saves the name of a sub-directory.
User If the QAPP extension “Windows File Server” has been activated:
Saves the name of the user.
Password If the QAPP extension “Windows File Server” has been activated:
Saves the password for access to the Windows file server.
