Operating Instructions Cubis
®
MCA 73
System Settings
Parameter Setting Values Explanation
Process accuracy
factor
Enter factor If this extension has been activated in the QAPP Center:
Savestheentry for the process accuracy factor.
Summand a(1) Enter summand If this extension has been activated in the QAPP Center:
Savestheentries for range 1.
Factor b(1) Enter factor
Exponent b(1) (e-) Enter exponent
Summand a(n) Enter summand If this extension has been activated in the QAPP Center:
Savestheentries for range n.
Factor b(n) Enter factor
Exponent b(n) (e-) Enter exponent
* Factory setting
7.7.24 Parameters in the “Device Settings / Device ID” Menu
Parameter Setting Values Explanation
Device ID 1 User input Saves the entered device ID.
Device ID 2 User input Saves the entered device ID.
7.7.25 Parameters in the “Device Settings / Electronic Signature” Menu
Parameter Setting Values Explanation
Sign report Off* If the QAPP extension has been activated:
Deactivates electronic signature.
On If the QAPP extension has been activated: Activates
electronic signature.
* Factory setting
7.7.26 Parameters in the “Device Settings / Draft Shield” Menu
(OnlyforDeviceswithaMotorizedDraft Shield)
Parameter Setting Values Explanation
Left | right palm
key
Off, no function Deactivates the function for both palm keys.
Same function Both palm keys perform the same learned draft shield function.
The two palm keys cannot be assigned functions independently
ofeach other.
Separate function* The two palm keys perform independent learned draft shield
functions. The two palm keys can be assigned functions
independently of each other.
* Factory setting
