Operating Instructions Cubis
®
MCA 43
Installation
5.4 Connecting the Ethernet Cable
Material: 1 Ethernet cable
1 soft support base
Tool: 1 Torx Allen key, T8
Procedure
t Turn over the electronics module with control unit and place
onasoftsurface.
t Remove the cover (3) of the Ethernet connection socket
ontheunderside of the display and control unit.
t Plug the Ethernet cable into the Ethernet connection socket.
t Place the Ethernet cable into the cable channel (1) and turn the cable
lock (2) using the network cable.
t Place the electronics module with control unit back on the device base
on a level surface.
5.5 Preparing Below-balance Weighing
The device can be configured for below-balance weighing. Samples can
besuspended for weighing using below-balance weighing, e.g. samples,
which do not fit on the weighing pan.
For below-balance weighing, the cover plate must be removed and the
device set up on a weighing table with recess.
In legal metrology:
− The below-balance weighing equipment may not be used.
− The cover of the below-balance weighing equipment may not
beopened.
Material: 1 soft support base
1 draft protection shield
1 weighing table with recess
Tool: 1 Torx Allen key, T20
3 2 1
