Operating Instructions Cubis
®
MCA 97
Technical Data
15 Technical Data
15.1 Dimensions and Weight
15.1.1 Microbalance
With round glass ring
draftshield
With stainless steel draft
shield for the filter pan
Unit Value Value
Dimensions
Weighing module (L × W × H) mm 340 × 139 × 129 340 × 139 × 129
Electronics module
with control unit (L × W × H)
mm 355 × 240 × 61 355 × 240 × 61
Weighing pan size
Weighing pan for models MCA2.7S mm Ø 20 Ø 20
Weighing pan for models
MCA10.6S, MCA6.6S, MCA3.6P
mm Ø 30 Ø 30
Filter weighing pan mm – Ø 50
Weight, approx. kg 7.2 7.9
15.2 Power Supply
15.2.1 Device
Only by Sartorius AC adapter YEPS03-15V0
15.2.2 AC Adapter
Unit Value
Item No. YEPS03-15V0
Primary
AC voltage V 100 – 240 (± 10%)
Frequency Hz 50 – 60 (± 5%)
Current consumption, maximum A 1.0
Secondary
DC voltage at 2 A output current V 14.25 – 15.75
Power, maximum W 30
Short circuit protection: Electronic
Protection class according to IEC 62368-1 I
