Overview
SEL provides many PC software solutions (applications) to support the
SEL-749M Motor Protection Relay and other SEL devices. Table 3.1 lists
SEL-749M software solutions.
This section describes how to get started with the SEL-749M and
ACSELERATOR QuickSet
®
SEL-5030 software. ACSELERATOR QuickSet is a
powerful setting, event analysis, and measurement tool that aids in setting,
applying, and using the SEL-749M. Table 3.2 shows the suite of
ACSELERATOR QuickSet applications provided for the SEL-749M.
Table 3.1 SEL Software Solutions
Part Number Product Name Description
SEL-5010 SEL-5010 Relay Assistant
Software
Manages a connection directory
and settings of multiple devices
SEL-5030
ACSELERATOR QuickSet
SEL-5030 Software
See Table 3.2
SEL-5031
ACSELERATOR QuickSet Designer
SEL-5031 Software
Customizes SEL-749M settings
for specific applications
SEL-5040
ACSELERATOR Report Server
SEL-5040 Software
Automatically retrieves, files,
and summarizes reports
SEL-5601
ACSELERATOR Analytic Assistant
SEL-5601 Software
Converts SEL Compressed
ASCII event report files to
oscillography
SEL-5801 SEL-5801 Cable Selector Software Selects the proper SEL cables for
your application
Ta b l e 3 . 2
ACSELERATOR QuickSet SEL-5030 Software
Terminal Provides a direct connection to the SEL device. Use this
communication method to interface directly with the device.
Rules-Based Settings
Editor
Provides on-line or off-line relay settings that include
interdependency checks. Use this feature to create and manage
settings for multiple relays in a database.
Event Analysis Provides oscillography and other event analysis tools.
Meter and Control Provides Human Machine Interface (HMI) for metering and
control features.
Setting Database
Management
ACSELERATOR QuickSet uses a database to manage the settings
of multiple devices.
Help Provides general
ACSELERATOR QuickSet and relay-specific
ACSELERATOR QuickSet context help.
