4.19

Date Code 20080918 Instruction Manual SEL-749M Relay

Protection and Logic Functions

Basic Motor Protection

Figure 4.9 Phase Reversal Element Logic

0.5 s

47T

E47T = Y

Voltage Option = Y

DELTA_Y = Wye

|VA|

|VB|

|VC|

|VAB|

|VBC|

60 V

0.5 • |V2|

0.25 • FLA

min

|V1|

|IA|

|IB|

|IC|

0.5 • |I2|

|I1|

35 V

Relay

Word

Bits

Relay

Inputs

I1, V1 and I2, V2 indicate positive-sequence

and negative-sequence quantities.

FLA

min

= Lowest Full Load Current Setting Allowed

Relay

Inputs
