Section 07 ELECTRICAL SYSTEM
Sub-Section 05 (INSTRUMENTS AND ACCESSORIES)
07-05-5
LAKE TEMPERATURE
Disconnect the 2-circuit connector housing of the
Info Center which contains a BLACK/ORANGE
and TAN/ORANGE wires.
Connect potentiometer test probes to the
BLACK/ORANGE and TAN/ORANGE wires.
Adjust potentiometer to the resistance values as
per following chart to test the accuracy of the
gauge.
NOTE:
The gauge must be activated to obtain a
reading.
EXTERIOR TEMPERATURE
Disconnect the 2-circuit connector housing of the
Info Center which contains a TAN/WHITE and
BLACK/WHITE wires.
Connect potentiometer test probes to the
TAN/WHITE and BLACK/WHITE wires.
Adjust potentiometer to the resistance values as
per following chart to test the accuracy of the
gauge.
NOTE:
The gauge must be activated to obtain a
reading.
Fuel Gauge/Low Oil Warning Light
SPX, GS, GTS, GTI, HX and XP Models
The fuel gauge has a pointer which indicates fuel
level in the tank.
The low oil warning light is part of the gauge. It
will light when injection oil level is low.
RESISTANCE
(
Ω
)
DISPLAY
TEMPERATURE (°C)
25407.3 5 ± 2
19911.1 10 ± 2
15718.0 15 ± 2
12495.0 20 ± 2
10000.0 25 ± 2
8054.9 30 ± 2
6528.3 35 ± 2
RESISTANCE
(
Ω
)
DISPLAY
TEMPERATURE (°F)
22799.0 45 ± 4
17262.0 55 ± 4
13470.0 65 ± 4
10496.3 75 ± 4
8264.4 85 ± 4
6528.3 95 ± 4
RESISTANCE
(
Ω
)
DISPLAY
TEMPERATURE (°C)
25590.1 5 ± 2
20005.8 10 ± 2
15761.7 15 ± 2
12510.2 20 ± 2
10000.0 25 ± 2
8047.8 30 ± 2
6518.7 35 ± 2
RESISTANCE
(
Ω
)
DISPLAY
TEMPERATURE (°F)
22919.8 45 ± 4
17491.7 55 ± 4
13487.5 65 ± 4
10501.5 75 ± 4
8252.0 85 ± 4
6518.7 95 ± 4
