22. If your scale calibration numbers are known, you can enter them here. If they are not, touch
next.
23. There are NO pressure sensors installed. Leave each pressure sensor defaulted to None and
then touch next.
24. There are NO height switches installed. Leave the box defaulted to None and then touch next.
25. Enter 2 into the Fan RPM 1 / RPM 2 Calibration Box. RPM 1 Low and High Limits will remain at
0. Touch next.
26. RPM 1 / RPM 2 sensor Assignments will be displayed. There should be a check mark defaulted
for each granular product. Touch next.
27. You will now setup the product control for each product. The 6 configuration pages will have the
same settings entered for each granular product (liquid differences in brackets). Touch next
after every page.
a. SETUP CONTROL VALVE PAGE
i. Control Type = PWM CLOSE
ii. Valve Response Rate = 50
iii. Control Deadband = 2
iv. Valve Delay = 0
v. Enable PWM Smart Control = YES checkmark
b. SETUP PWM PAGE (SKIPPED IF PWM IS NOT CHOSEN WITH LIQUID PRODUCT)
i. Coil Frequency = 65
ii. PWM High Limit = 90 (100 – liquid)
iii. PWM Low Limit = 25 (1 – liquid)
iv. PWM Startup = 0.0
c. SETUP Rate Sensor PAGE
i. Calibration Weight = 2.958 (CALIBRATION REQUIRED)
ii. Pulses / Revolution = 60.00
iii. Flowmeter Calibration = Value located on flowmeter (liquid only)
iv. Flowmeter Pulse / Units = 10 gal. (liquid only)
d. SETUP Tank / Bin PAGE
i. Tank Fill / Level Sensor = Select appropriate sensor if installed (liquid only)
ii. Tank Capacity = 0 (Enter in gallons for liquid)
iii. Current Tank Level = Enter value in gallons if not empty (liquid only)
iv. Low Tank Level = 0 (Enter in gallons for liquid if alarm is desired)
v. Low Bin Level Sensor = NO checkmark
vi. Max Tank Fill PWM = 100% (liquid only)
e. SETUP Rates PAGE
i. Preset Rate Values: Rate 1 = 150 (25 liquid), Rate 2 = 0, Rate 3 = 0
ii. Rate Bump = 10 (1 liquid)
iii. Rate Selection = Rate Bump or Rx
iv. Display Smoothing = YES checkmark
v. Decimal Shift = 1
f. SETUP Alarms PAGE
i. Off Rate Alarm = 30 with checkmark
ii. Shaft Sensor Alarm = NO checkmark
iii. Minimum Flow Rate = Enter value in gallons if required to maintain rate
accuracy (liquid only)
The setup is complete. Repeat the settings above for each product until the setup wizard gets to the
setup summary page. Please review the setup summary page then touch next.
