Using the EM 6000

106

Info

This menu item shows the MAC address of the Dante™ interface and the

current version of the Dante™ firmware. You cannot configure any settings

here.

►

You can find information about updating the Dante™ firmware under

“Updating the firmware of the Dante™ interface”.
