Accessories

20

BA 61 rechargeable battery

The BA 61 rechargeable battery is intended to operate the SK 6000

bodypack transmitter.

►

Sennheiser article number 504703

B 61 battery compartment

The B 61 battery compartment is intended to operate the SK 6000

bodypack transmitter.

►

Sennheiser article number 504701
