Specifications
160
EM 6000
►
Receiving channels 2
Receiver principle Double superheterodyne
Diversity True bit diversity
Frequency range 470 to 714 MHz
Sensitivity -100 dBm, typical
Image rejection > 100 dB, typical
Blocking > 80 dB, typical
Audio frequency response 30 Hz to 20 kHz (1.5 dB)
Analog audio outputs One XLR-3 and 6.3 mm (1/4") jack
per channel (transformed-bal-
anced),
-10 dBu to +18 dBu in steps of 1 dB
(2 kΩ)
Digital audio outputs AES3-2003, XLR-3: 48 kHz,
96 kHz, 24 bit
Can be externally synchronized
using WCLK loop-through with
BNC sockets
Headphone output 6.3 mm (1/4") jack,
2× 100 mW at 32 Ω
Antenna inputs 2× BNC (50 Ω)
Daisy chain outputs 2× BNC (50 Ω)
0 dB +/- 0.5 dB amplification rel-
ative to antenna inputs
Daisy-chained receivers (HF) Max. 8 EM 6000 units
Booster supply voltage 12 V DC, max. 200 mA each via
antenna sockets, short circuit
proof
Word clock input BNC, 75 Ω
Word clock output BNC, 75 Ω
Word clock sampling rates 48 kHz, 96 kHz
Network IEEE 802.3-2002 (10/100 Mbit/s),
shielded RJ-45 connection
Power supply 100 to 240 V AC, 50/60 Hz
Power consumption Max. 35 W
Power plug 3-pin, protection class I as per
IEC/EN 60320-1
Dimensions (H × W × D with
mounting elements)
44 × 483 × 373 mm (1 3/4" x 19" x
14 11/16")
Weight approx. 5.2 kg (11 lbs 7 oz)
