Specifications
164
SK 6000
►
Frequency range 470 to 718 MHz
Different frequency variants: see
“SK 6000 product variants”
Switching bandwidth 88 MHz
Frequency stability < 5 ppm
Tunability 25 kHz steps
Lower frequency limit (-3 dB) Mic: adjustable, 60 Hz, 80 Hz,
100 Hz, 120 Hz
Instruments/line: 30 Hz
RF output power 25 mW rms, 50 mW peak
Audio frequency response Line: 30 Hz to 20 kHz (3 dB)
Mic: 60 Hz to 20 kHz (3 dB)
Audio amplification Mic: adjustable in 3 dB steps from
0dB to +42dB
Instruments: adjustable in 3 dB
steps from -6 dB to +42 dB
Line: adjustable in 3 dB steps
from -6 dB to +42 dB
Mic/line input 3-pin audio socket
Instrument cable emulation Adjustable cable length with 3
steps
Antenna output Coaxial socket
Operating time 6.5 h (with BA 61 accupack)
Power consumption Max. 960 mW
Dimensions (H × W × D) 76 × 62 × 20 mm (3" x 2 7/16" x 3/
4")
(with BA 61 accupack)
Weight approx. 147 g
(with BA 61 accupack and belt
clip)
