Sharp IV-S20 User Manual

6- 21
Installation Conditions and Method
6
External dimensions of camera angle bracket
External dimensions of camera body (IV-S20C1) and camera lens (IV-S20L16)
28
22.5
5.5
39
31
17
10°10°
60°
20
20
3.2
28
25
1/4-20 UNC threaded hole
(for attachment to the mounting surface)
2 slotted holes 3.2 mm wide
(for attachment to the mounting surface)
4 slotted holes wide
(for securing on the camera body)
(Unit: mm)
(Unit: mm)
30
32
20
※
30
55
37
20
※
32
5
7
37
7
2 M3 tapped holes
2 M3 tapped holes
2 M3 tapped holes
※ Attach the camera angle bracket to
one of the tapped M3 holes 20 mm
mounting pitch (3 places).
28.5 〜 34
3
37 25
20
※
32
5
7
2863 52.2
φ7
φ16.9
