9·48
Degree of match inspection
9
Continued from the previous page.
Continued on the following page
1MEAS WINDOW(MDL0) RECTANGLE
X-LINE Y-LINE
2REF IMAGE(MODEL0) MOVE UP.L(224,208) LO.R(287,271) REG. DISP
3SEARCH AREA(MDL0) MOVE UP.L(
216,200)
LO.R(
295,279)
4DTECT COORD(MDL0)
CNTR FREE(256,240)
5CONTR. PIXEL(MDL0)
1 2 3
6MEAS WINDOW(MDL1) RECTANGLE
X-LINE Y-LINE
7REF IMAGE(MODEL1) MOVE UP.L(224,208) LO.R(287,271) REG. DISP
8SEARCH AREA(MDL1) MOVE UP.L(
224,512)
LO.R(
287,512)
9DTECT COORD(MDL1)
CNTR FREE(256,240)
0CONTR. PIXEL(MDL1)
1 2 3
qDETECT ACCURANCY
STANDARD HI-PRC
wUPPER MENU
Select item 5 EVALUATE CRITERIA (criteria conditions)
This is how the display looks when the
GRAY-IMG-PROC (gray scale processing)
mode is selected.
Go to page 9·51.
To see how the display looks when the BINRY-
IMG-PROC (binary processing) mode is selected.
This is displayed when YES
(SEARCH) (yes-search yes)
is selected for model 1.
These entries are displayed
when YES (NO-SEARCH)
(yes-search no) or YES
(SEARCH) (yes-search yes)
is selected for model 1.
These entries are displayed
when SEARCH (search yes)
is selected for model 0.
· You can switch between displaying all of the headings together and displaying each one
separately, using the ESC key.
Menu
1MEAS WINDOW(MDL0)
(measurement window)
2REF IMAGE(MODEL0)
(reference images)
3SEARCH AREA(MDL0)
(search area )
4DTECT COORD(MDL0)
(detection coordinates)
5CONTR. PIXEL(MDL0)
(pixel contraction)
6MEAS WINDOW(MDL1)
(measurement window)
7REF IMAGE(MODEL1)
(reference image)
8SEARCH AREA(MDL1)
(search area)
9DTECT COORD(MDL1)
(detection coordinates)
0CONTR. PIXEL(MDL1)
(pixel contraction)
qDETECT ACCURANCY
(accuracy of detection)
wUPPER MENU
Setting details
Select the measurement window shape for model 0 (positioning).
Record a reference image for model 0
· The upper left or lower right area of the screen specified above will
change according the setting in item 1.
If model 0 is set to SEARCH (search), then enter the search area.
Set the position of the cursor inside the measurement window for
model 0.
· If FREE is selected, then the position of cursor is optional.
If model 0 is set to SEARCH (search yes), then enter the pixel
contraction level.
-See (page 9·6) gray scale processing, in shared settings.
· When either X-LINE (horizontal line) or Y-LINE(vertical line) are
selected in item 1, you can select only 1 or 2 in item 5.
The settings for these are the same for model 1 as they are for model
0, numbers 1 to 5.
Set the level of detection precision for models 0 and 1.
-See page 9·6 “Gray scale processing” in shared settings.
This will return you to the [MEASURING COND] (measurement
conditions) menu.
The selection
at item 1
RECTANGLE(rectangle)
X-LINE (horizontal line)
Y-LINE (vertical line)
The display in the upper left,
lower right areas of the screen.
Upper left, lower right.
Starting point, end point
To Next Page
